SPECIFICATIONS
Material | ABS Polymer Construction |
---|---|
Outlets | 6 |
Cammed | 6 Zone |
Use | Reclaimed Water |
Flow Rate | 38 – 95 l/pm |
Pressure | 170 – 520 kPa |
Inlet | 32mm (1 1/4″) |
Outlet | 25mm (1″) |
This valve is constructed of high strength, non-corrosive ABS polymer and is cammed for 6 Zone Operation. These patented indexing valves allow for the number of watering zones to be changed quickly and easily. They are ideally suited for both city water and pump applications and may also be used for onsite wastewater or effluent water applications. The simplicity of design and few moving parts ensures ease of maintenance and long service life.
Material | ABS Polymer Construction |
---|---|
Outlets | 6 |
Cammed | 6 Zone |
Use | Reclaimed Water |
Flow Rate | 38 – 95 l/pm |
Pressure | 170 – 520 kPa |
Inlet | 32mm (1 1/4″) |
Outlet | 25mm (1″) |
The 4000 offers a reliable, economical way to automate multiple zoned residential and small commercial irrigation systems. These patented indexing valves allow for the number of watering zones to be changed quickly and easily. They are suited for both city water and pump applications and may also be used for onsite wastewater or effluent water applications. This valve is constructed of high strength, non-corrosive ABS polymer and is cammed for 6 Zone Operation.
Code | Model | Description |
---|---|---|
KR4600 | 4000 Series 32mm | 6 Outlet |
KR4600RCW | 4000 Series 32mm | 6 Outlet RCW |
KR4602RCW | 4000 Series 32mm | 6 Outlet / 2 Zone RCW |
KR4603RCW | 4000 Series 32mm | 6 Outlet / 3 Zone RCW |
KR4604 | 4000 Series 32mm | 6 Outlet / 4 Zone |
KR4604RCW | 4000 Series 32mm | 6 Outlet / 4 Zone RCW |
KR4605 | 4000 Series 32mm | 6 Outlet / 5 Zone |
KR4605RCW | 4000 Series 32mm | 6 Outlet / 5 Zone RCW |
KR4606 | 4000 Series 32mm | 6 Outlet / 6 Zone |
KR4606RCW | 4000 Series 32mm | 6 Outlet / 6 Zone RCW |
