Performance Data
Download Full Performance Data
Pattern | Pressure (kPa) | Radius (m) | Flow Rate (L/min) | Precip. (mm/hour) / |
---|---|---|---|---|
90° | 138 170 275 345 | 3.4 3.7 4.0 4.3 | 1.89 2.65 3.03 3.41 | 40 / 47 47 / 55 46 / 53 45 / 52 |
180° | 138 170 275 345 | 3.4 3.7 4.0 4.3 | 4.54 5.30 6.44 7.57 | 32 / 37 32 / 37 33 / 38 33 / 38 |
360° | 138 170 275 345 | 3.4 3.7 4.0 4.3 | 6.06 6.81 7.95 9.08 | 32 / 37 31 / 35 30 / 35 30 / 35 |
