Additional information
Thread | Female |
---|
This product has been discontinued
Spray nozzles are important, but often an overlooked component of a well-designed irrigation system. The proper nozzle ensures accurate, even delivery of water in the pattern you need. Female Thread fixed Nozzles have matched precipitation for even water distribution. Available in six fixed patterns, providing an array of system configurations. Extra long filters provide longer time between cleanings.
Thread | Female |
---|
Download Full Performance Data
Pattern | Pressure (kPa) | Radius (m) | Flow Rate (L/min) | Precip. (mm/hour) |
---|---|---|---|---|
90° | 138 207 276 | 3.7 4.3 4.6 | 2.8 3.1 3.5 | 59 47 46 |
180° | 138 207 276 | 3.7 4.3 4.6 | 5.7 6.2 7.0 | 59 47 46 |
360° | 138 207 276 | 3.7 4.3 4.6 | 11.4 12.5 14.0 | 59 47 46 |
Code | Description | Throw | Spray | Quantity |
---|---|---|---|---|
KNF12Q | 12′ Female Thread | 3.6m | 90° Quarter Spray | 1 |
KNF12H | 12′ Female Thread | 3.6m | 180° Half Spray | 1 |
KNF12F | 12′ Female Thread | 3.6m | 360° Full Spray | 1 |
KNF15Q | 15′ Female Thread | 4.5m | 90° Quarter Spray | 1 |
KNF15H | 15′ Female Thread | 4.5m | 180° Half Spray | 1 |
KNF15F | 15′ Female Thread | 4.5m | 360° Full Spray | 1 |
KNF12QTP | 12′ Female Thread Bulk | 3.6m | 90° Quarter Spray | 20 |
KNF12HTP | 12′ Female Thread Bulk | 3.6m | 180° Half Spray | 20 |
KNF12FTP | 12′ Female Thread Bulk | 3.6m | 360° Full Spray | 20 |
KNF15QTP | 15′ Female Thread Bulk | 4.5m | 90° Quarter Spray | 20 |
KNF15HTP | 15′ Female Thread Bulk | 4.5m | 180° Half Spray | 20 |
KNF15FTP | 15′ Female Thread Bulk | 4.5m | 360° Full Spray | 20 |
